PV input

Max. input power

12000W

15000W

18000W

22500W

Max. input voltage

550V

Start-up voltage

120V

MPPT voltage range

120V~480V

Max. input current

26A

Max. short circuit current

39A

Number of MPPT/max. number of PV strings

3/2+2+2

Battery input/output

Battery voltage range

40V~60V

Max. charge/discharge current

167A

210A

250A

245A

Max. charge/discharge power

8000W

10000W

12000W

15000W

Battery BMS communication

RS485/CAN

AC output (EPS & Smart)

Rated output power

8000W

10000W

12000W

15000W

Max. apparent output power

8000VA

10000VA

12000VA

15000VA

Rated output current

33.4A

41.7A

50A

62.5A

Rated output voltage/frequency

120/240V (Split phase), 208V(2/3 phase), 60Hz

Power factor

>0.99(0.8 leading~0.8 lagging)

THDi

<3%@rated power

EPS switching time

<10ms

Starting surge

10s@2×rated power

THDu

<3%(linear load)

AC input (Grid & Gen)

Max. AC charging power(grid to battery)

8000W

10000W

12000W

15000W

Max. grid input current

50A

62.5A

Max. diesel generator input current

50A

62.5A

Rated input voltage/frequency

120/240V (Split phase), 208V(2/3 phase), 60Hz

Efficiency

Max. efficiency

97.50%

European efficiency

96.50%

MPPT efficiency

99.50%

General parameters

Display

LCD+APP

Communications

RS485/WiFi/CAN (Optional: Bluetooth/LAN/4G/Meter)

IP rating

lP66

Operating temperature

-25℃~+60℃(-13℉~+140℉), >+45℃(+113℉) derating to 60%

Humidity

0~95%(non-condensing)

Cooling mode

Intelligent air cooling

Noise level

<45dB

Dimensions (W×H×D)(mm)

466×756×242

Net weight (kg)

45
