PV input

Max. input power

60kW

80kW

100kW

Max. input voltage

1000V

Start-up voltage

200V

MPPT voltage range

150~850V

Max. input current

20A

Max. short circuit current

30A

Number of MPPT/max. number of PV strings

4/2+2+2+2

Battery input/output

Battery voltage range

135~850V

Max. charge/discharge current

100A

Max. charge/discharge power

30kW

40kW

50kW

60kW

Battery BMS communication

RS485

AC output (EPS & Smart)

Rated output power

30kW

40kW

50kW

60kW

Max. apparent output power

30kVA

40kVA

50kVA

60kVA

Rated output current

45.6A/43.3A

60.8A/57.7A

76A/72.2A

91.2A/86.6A

Rated output voltage/frequency

380V/400V, 3L+N+PE, 50Hz/60Hz

Power factor

0.8 leading~0.8 lagging

THDi

<3%@rated power

EPS switching time

<20ms

Starting surge

30s@1.1×rated power/10s@1.2×rated power/0.2s@1.5×rated power

THDu

<3%(linear load)

AC input (Grid & Smart)

Max. AC charging power(grid to battery)

30kW

40kW

50kW

60kW

Max. grid input current

91.2A

121.6A

152A

182.4A

Max. diesel generator input current

45.6A/43.3A

60.8A/57.7A

76A/72.2A

91.2A/86.6A

Rated input voltage/frequency

380V/400V, 3L+N+PE, 50Hz/60Hz

Efficiency

Max. efficiency

98.5%

European efficiency

97.50%

MPPT efficiency

99.90%

General parameters

Display

LCD

Communications

Ethernet, RS485, 4G/WiFi

IP rating

lP66

Operating temperature

-25℃~+60℃(>45℃ linear derating to 60%)

Humidity

<95%(non-condensing)

Cooling mode

Air cooling

Noise level

<65dB

Dimensions (W×H×D)(mm)

544×880×278

Net weight (kg)

88
